Vacuum leak detection for peace of mind
Durable anodized aluminium body, neutrally buoyant
Specially designed domes for clean zenith and nadir
7-color LED indicator shows camera status at a glance
Underwater start/stop to conserve disk space and battery.
Underwater on/off to conserve battery.
3x 18650 batteries to extend recording time.
Easy setup with included App.
4x external bulkhead ports for hydrophone, ethernet, power, vacuum valve, etc.
Clean nadir and zenith—full 3D/360 view, no black discs/occlusions
10mm port for observing Insta360 display
Wifi for control, setup (surface), web interface to controller for remote control and log files
Underwater on/off, start/stop
Support for hydrophone in top bulkhead (M14 or M16)
Support for Ethernet and HDMI connection through bottom M16 bulkhead for live-streaming / remote control
Battery pack to extend runtime of Insta360 Pro
Vacuum valve installed as standard
Supported camera: Insta 360 Pro/Pro 2 (not included)
Material: Anodised aluminium
Colour: Black
Safe depth rating: 90m / 300ft
Buoyancy: 300g/10oz positive in saltwater, 200g/7oz positive in freshwater
Dimensions (with domes): 250mm high, 218mm wide, 198mm depth
Dimensions (without domes): 250mm high, 162mm wide, 144mm deep
Weight: 2.2kg without camera or batteries, 3.7kg with camera, batteries
External controls: Power on/off, record, stop, switch controller
Batteries: 3x 18650 (to power electronics and increase camera battery capacity)
Run time: 12 hours standby, 90 minutes continuous recording
Top: 2x M14, 1x M16
Bottom: 1x M16
MOUNTING POINTS
Top: 15x 1/4-20 UNC, 9mm spacing
Bottom: 16x 1/4-20 UNC, 9mm spacing
Front: 1x 3/8-16 UNC
Back: 1x 3/8-16 UNC
6x domes, mounted
1x 2mm hex key for domes
1x O-ring kit
1x O-ring grease
2x Anodes, installed
1x Nauticam M14 Vacuum Valve II (push-button release) installed as standard
1x M14 port plug, installed
2x M16 port plug, installed
1x Camera tray with battery shuttle and Mantis electronics
1x Pelican case (suitable as carry-on cabin baggage), with custom foam
2x 2dBi SMA stub antennas (replace Insta360 standard to fit inside housing)
1x Ethernet cable
NOT INCLUDED
Camera (Insta360 Pro or Pro2)
SD/MSD cards for Pro/Pro2 (7x cards required)
Li-ion batteries (3 x 18650)
Battery charger for 18650 batteries
